This is a specification for the KD056VGTPA004-SP001A-HDMI module. It's a 5.6" TFT - LCD with HDMI interface, 640x480 resolution, 65K/262K colors. The module features details on mechanical, electrical, optical characteristics, pin assignments, and quality control standards, along with handling precautions and reliability test results.
High-Resolution Display
The KD056VGTPA004-SP001A-HDMI module features a 5.6" TFT - LCD with a resolution of 640x480 pixels. This provides a clear and detailed visual experience. With the ability to display up to 65K/262K colors, images and videos appear vibrant and true to life. The pixel pitch of 0.18(H) * 0.18(V) mm ensures sharpness. The viewing angle of 12:00 o'clock allows for comfortable viewing from various positions. Whether used for gaming, media playback, or other applications, the high-resolution display is a standout feature.
HDMI Interface Compatibility
This module comes with an HDMI(Type A) interface, offering wide compatibility. It can be easily connected to a variety of devices such as Windows 7/8/10 computers, Android devices, Linux systems, and Raspberry Pi. This allows for seamless integration into different setups. The HDMI connection enables high-quality audio and video transmission, ensuring a great multimedia experience. With the correct HDMI cable, users can quickly set up and start using the module without any hassle, making it a convenient choice for many applications.
Robust Mechanical Design
The module has a well-designed mechanical structure. Its horizontal size is about 126.50 mm, vertical size is 100.00 mm, and depth is 5.70 mm, with a weight of 123 g. This compact and sturdy design makes it suitable for various installations. The module is built to withstand normal handling and operating conditions. It is carefully engineered to ensure that all components are properly housed and protected. The mechanical design also takes into account factors such as heat dissipation and durability, ensuring a long lifespan for the module.
Precise Electrical Characteristics
The electrical characteristics of this module are precisely defined. The power supply voltage has specific limits, with a DC 12V input for power and various voltage requirements for different pins. The normal mode current consumption is specified as - 60 - 120 mA when DC_IN = 12V. These precise electrical parameters ensure stable operation of the module. It is designed to work within a certain temperature range (-20 to +70 °C for operating and -30 to +80 °C for storage), further enhancing its reliability and performance.
Stringent Quality Control
Stringent quality control measures are in place for the KD056VGTPA004-SP001A-HDMI module. The visual & function inspection standard includes detailed criteria for various aspects such as functional defects, missing components, outline dimensions, color tone, and spot/line defects. Sampling is done according to GB/T 2828 - 2003, with defined AQL values for major and minor defects. Reliability tests such as high temperature and humidity tests, thermal shock tests, and ESD tests are conducted to ensure the module meets high-quality standards and can perform reliably in different environments.
